| Model | OCBP-T4202 | OCBP-T4302 |
| Color | Black |
| Processor | 32bit CPU |
| Optional interface | USB2.0(standard)/USB+BT/USB+BT+WIFI/USB+LAN |
| Real time clock | Standard |
| Printer language | TSPL |
| Printer head life | 100Km |
| Power supply | Input: AC 100V-240V, 50-60Hz, Output: DC 24V/2.5A |
| Sensors | Gap sensor, Cover opening sensor, Black mark sensor, |
| Memory | 8MB Flash Memory/8MB SDRAM/Flash memory |
| Accessories | Quick start guide, USB cable, Power cord, Label spindle |
| External universal switching power supply, fixing tab x 2, 1.5” core adapter x 2, Ribbon spindle x 2, Ribbon paper core |
| software | Driver: Windows/Mac SDK: Windows/Android/iOS |
| Printing method | Thermal Transfer / Direct Thermal |
| Resolution | 8 dots/mm(203 DPI) | 12 dots/mm(300 DPI) |
| Max. print speed | 152 mm (6”) /s | 127 mm (5”) /s |
| Max. print width | 104 mm (4.09”) | 104 mm (4.09”) |
| Max. print length | 1778mm (70”) | 889 mm (35”) |
| Graphics printing | BIMAP, BMP, PCX(Max. 256 colors) |
| Barcode | 1D barcode:Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on,MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 112D barcode: PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Internal fonts | 8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software. |
| Font and barcode rotation | 0°, 90°, 180°, 270° |
| Graphic | BIMAP, BMP, PCX(Max. 256 colors) |
| Media type | Continuous, die-cut, black mark, fan-fold, notched (outside wound) |
| Media width | 20-112mm (0.78”-4.4”) |
| Media thickness | 0.06 ~ 0.254 mm (2.36 ~ 10 mil) |
| Label length | 10 ~ 1178 mm (0.39” ~ 70”) | 10 ~ 889 mm (0.39” ~ 35”) |
| Label roll capacity | 127 mm (5”) OD (outside diameter) |
| Ribbon capacity | 300m long Max |
| Ribbon width | 110mm |
| Ribbon core inner diameter | 25.4 mm (1″) |
| Dimension | 280mm*210mm*170mm |
| Weight | Net: 2.25kg Gross: 3.25kg |
| Package box | 370*240*205mm |
| 4 in 1 carton | 500*390*430mm/14.5kg |
| Working temperature& humidity | 0 to 45 degrees centigrade, 10%~80% No condensation |
| Storage temperature& humidity | -20 to 60 degrees centigrade, 10%~90% No condensation |
