KDS-181

KDS-181
KDS-181 - Image 2
KDS-181 - Image 3
KDS-181 - Image 4
KDS-181 - Image 5
KDS-181 - Image 6

KDS-181

Category
  • High-Brightness Full HD IPS
    1920×1080 IPS screen with 300nit brightness provides crystal-clear visual performance.
  • Robust Aluminium VESA Housing
    Aluminium shell enables fast cooling and supports universal VESA wall mounting standards.
  • Simple “One-Line” Secondary Display
    Supports convenient “one-line” connection for secondary displays to reduce complex wiring.
Get a quote

Vibrant Large-Scale Display

18.5-inch HD touch screen with 1366*768 resolution and 178° wide viewing angles

Industrial-Grade Metal Build

Durable aluminum and metal housing for superior heat dissipation and stability

Dual-OS Platform Flexibility

Supports Windows 10 Pro with Celeron J4125 or Android 11 with RK3566 processor

Responsive Capacitive Touch

Multi-point projected G+G capacitive touch for smooth and accurate operation

High-Speed Network Integration

Equipped with Gigabit LAN, Wi-Fi, and Bluetooth 4.0 for stable data transmission

Flexible Mounting Design

Compact structure with standard VESA holes for easy wall-mounting or stand installation

ModelKDS-181-WKDS-181-A
Name18.5 inch Windows or Android machine
Housing materialAluminium and metal housing
Display
Main screen size18.5 inch touch screen monitor
Resolution1366*768
Brightness250cd/㎡
View angleHorizon: 178° Vertical :178°
Touch screenmulti-point projected G+G capacitive touch, resistive touch for option
Performance
MotherboardCeleron J4125 ,quad core 2.0GRock-chip series RK3566 ,quad core 1.8G
System Memory4GB DDR4On board 4GB DDR4
Storage deviceMini SATA 128GBOn board 32GB eMMC
LAN10M/100M/1000M LAN card10M/100M/1000M LAN card
WIFISupport 2.4G (2.4G&5G dual frequency for option)
BluetoothSupport BT 4.0
Speaker8 Ohm/3W*1
Operating SystemSupport Windows 10 ProAndroid 11
Connectivity12V DC in jack*1
Power button*112V DC in jack*1
Power button*1USB*4
LAN:RJ-45*1		USB*2
LAN:RJ-45
Packagepackage
Product dimension&Weight456*277*57mm /4.5kg
Package dimension&Weight551*149*380mm /5.5Kg
Accessories
Power adapter110-240V/50-60HZ AC power input ,DC12V/5A output
Power cablePower cable plug compatible with USA /EU / UK etc and customized available
